In this article, author Urs Hugentobler looks at the history of laser ranging to navigation satellites, how that ranging has improved the accuracy of the orbits of those satellites and what the future portends for this important contribution to space geodesy.

THE LASER. It might not be in the top 10 of the most important inventions of all time, but Time magazine rated it among the most important developments of the 20th century, listing it fifth after the automobile, the radio, the television and the transistor. Lasers are now ubiquitous: they scan our purchases at the supermarket checkout; they let us read and write data on compact discs; they have replaced the scalpel in many operating theaters; and they play major roles on the battlefield with laser-guided munitions. However, one of the first practical uses of the laser was in precisely determining the orbits of satellites.

Initial experiments in ranging to satellites carrying corner-cube retroreflectors began in 1964 just a few years after the laser was invented in 1960. Satellite laser ranging (SLR) stations were built in several countries, and a number of multi-instrument satellites with retroreflectors were launched by the U.S. and other nations along with dedicated spherical satellites with no electronic instrumentation — just the retroreflectors covering the satellite’s surface. The first of these was the Laser Geodynamics Satellite, or LAGEOS. It was designed by NASA and launched in 1976. LAGEOS and the other satellites carrying retroreflectors played a significant part in NASA’s Crustal Dynamics Project (CDP). Initiated in 1979, the CDP promoted the use of SLR and very long baseline interferometry to improve our understanding of plate tectonics, the rotational dynamics of the Earth, and the structure of the Earth’s gravity field.

As a post-doctoral fellow at the Massachusetts Institute of Technology and later at the University of New Brunswick, I participated in the CDP with analyses of lunar laser ranging (LLR) data. Ranging to reflectors placed on the moon’s surface by Apollo astronauts as well as those on the Russian Lunokhod rovers was a bit more difficult than ranging to satellites given the larger distances to the reflectors and the much weaker return pulses. Among other advances, LLR was the first technique to confirm the existence of variations in the spin of the Earth with a periodicity of around 50 days.

But let’s get back to SLR. Today, thanks in large measure to the International Laser Ranging Service, ranging data is routinely collected on more than 70 satellites and lunar reflectors. Included is a growing list of GNSS satellites equipped with corner-cube retroreflectors. Laser ranging to GNSS satellites is instrumental is better modeling the orbits of these satellites. Among other benefits, better GNSS satellite orbits result in better receiver position accuracies — accuracies needed to improve monitoring of crustal strain, for example, including that associated with earthquakes.

In this month’s column, we take a look at the past, present and future of laser ranging to GNSS satellites and how laser ranging and microwave ranging are mutually beneficial. They are truly kindred spirits.

---

Satellite laser ranging or SLR has been an indispensable independent tool for validating the precise orbits determined for GNSS satellites using microwave pseudorange and carrier-phase observations for several decades. SLR has allowed researchers to identify several orbit-modeling issues. Adding albedo radiation pressure and antenna thrust, among other effects, into the GPS orbit model allowed them to eliminate the observed bias between microwave- and SLR-derived orbits. For the first Galileo satellites launched, SLR residuals indicated severe orbit modeling issues caused by the different shape of Galileo satellite bodies compared to those of GPS. In the future, all GNSS satellites will be equipped with laser retroreflectors, a big challenge for researchers concerning tracking scenarios and observation planning to make economic use of the ground equipment.

In this article, we will take a brief look at the history of laser ranging to navigation satellites, how that ranging has improved the accuracy of the orbits of those satellites, and what the future portends for this important contribution to space geodesy.

VALIDATION OF GNSS ORBITS

In 1964, only four years after Theodore Maiman built the first laser, the first laser echoes were obtained from NASA’s Explorer 22 satellite. SLR rapidly developed into an indispensable tool for precise orbit determination, gravity field determination, and Earth system research.

FIGURE 1 shows the principles of SLR operation. Essentially, an SLR station fires a series of laser pulses at passing satellites equipped with corner-cube retroreflectors, and the relatively few photons returned are collected by a telescope. The station electronics measures the round-trip travel times of the laser pulses. From these measurements, the coordinates of the SLR station or the satellite’s orbit can be determined.

Observations by a global network of SLR stations are coordinated by the International Laser Ranging Service (ILRS), which, like the International GNSS Service, is one of the space geodetic services of the International Association of Geodesy (IAG).

Since the early 1990s, the ILRS has tracked GNSS satellites supporting the independent validation of the microwave-derived precise orbits. Two Block IIA GPS satellites, SVN35 and SVN36, were equipped with retroreflectors (see FIGURE 2) and they were routinely tracked from their launches in 1993 and 1994, respectively, until their decommissioning in 2013 and 2014 (actually, SVN36 was subsequently briefly reactivated in 2015 so data is available for that satellite until that year). Also in the 1990s, the ILRS started to track GLONASS satellites in support of the International GLONASS Experiment (IGEX-98). There is a retroreflector array on all GLONASS satellites (see FIGURE 3).

Range residuals of GPS and GLONASS satellites were studied in the early years by a number of different research groups. Most of their analyses showed a bias of about –5.5 centimeters for GPS satellite orbits derived from microwave tracking data by the IGS while the accuracy of the latter was estimated to about 5 centimeters. For GLONASS orbits, a negative bias of about –4 centimeters was identified, too. The accuracy of the orbits was, however, at the 10–15 centimeter level. These validation results supported several model improvements for GPS satellite orbits including, in particular, the handling of solar and Earth albedo radiation pressure and antenna thrust, reducing the observed SLR bias with respect to the IGS orbits to 1.3 centimeters with a standard deviation of about 2 centimeters.

“What are radiation pressure and antenna thrust?” you might ask. The photons making up the light coming directly from the sun or reflected from the Earth’s surface (albedo) impinge on a satellite and transfer some of their energy to it. Solar radiation pressure – the force due to the impact of the photons – is tiny, but its continuing presence has a strong perturbing effect on satellite orbits. Antenna thrust is also a small force. The transmission of GPS navigation signals results in a continuously acting reactive force in the radial direction acting on the satellite.

SLR also plays an essential role for calibrating improved radiation pressure models for the new satellite systems. All Galileo satellites have retroreflectors (see FIGURE 4), and the orbits of the first satellites to be launched, generated using the classical extended radiation pressure model of the Center for Orbit Determination in Europe (operating in the framework of the IGS Multi-GNSS Pilot Project or MGEX), had SLR residuals as large as 20 centimeters for passes with a small beta angle. (The beta angle is the angle between the sun and a satellite’s orbital plane.) The origin of this behavior is the elongated shape of the Galileo satellites compared to the more-or-less cubic shape of GPS satellites, causing much larger variations of the satellite cross-section exposed to the sun while orbiting the Earth. The observed SLR residuals triggered the development of improved radiation pressure models for Galileo satellites.

All BeiDou satellites are also believed to be equipped with retroreflectors (see FIGURE 5). As the estimated longitude of geostationary GNSS satellites such as those in the BeiDou constellation is highly susceptible to biases due to the small motion of the satellites with respect to the tracking stations, SLR may play an important role for precise orbit determination of this category of satellite.

The satellites of the Indian Regional Navigation Satellite System (IRNSS), also known as the Navigation with Indian Constellation system or NavIC, also carry retroreflectors (see FIGURE 6) and have been tracked by SLR stations. However, little publicly available microwave tracking data yet exists. Therefore, up to now, precise orbit determination heavily relies on SLR observations.

MORE APPLICATIONS OF SLR FOR GNSS

Because GNSS is a one-way measurement technique, only pseudoranges and carrier phases can be measured, and clock synchronization is indispensable for positioning and orbit determination. Radial orbit errors can therefore be absorbed to a large degree by satellite clock corrections. For the very stable clocks on board Galileo satellites, the SLR residuals show the same behavior as the microwave-derived clock corrections indicating that the clock corrections are, in fact, caused by radial orbit errors. SLR therefore provides a way to break this correlation and to separate radial orbit errors and satellite clock corrections. This makes it possible to study and to characterize the physical behavior of onboard clocks including temperature-induced clock variations.

Separation of orbit errors and satellite clock variations is crucial when using the first two Full Operational Capability Galileo satellites, which were released into wrong orbits, for relativistic experiments. In a dual launch on Aug. 22, 2014, the two satellites were put into orbits with an initial eccentricity of 0.233 and orbit height of 19,800 kilometers due to a malfunction of the launcher third stage. With a sequence of maneuvers, the satellite orbit heights could be increased to 22,600 kilometers (compared to the planned height of 23,200 kilometers) and the eccentricity was decreased to 0.156. The satellites are, nevertheless, fully functional, and the very stable hydrogen masers on board should allow scientists to improve the uncertainty of the relativistic redshift parameter α beyond the current value determined in 1976 using the Gravity Probe A satellite. Regular SLR tracking of the two satellites plays an essential role in this experiment to separate clock variations due to orbit errors from those caused by the gravitational redshift.

Eventually, SLR may also be used as a tool for high-precision time synchronization of stable GNSS clocks combining one-way laser transmissions with two-way active laser operation, similar to the concept of the European Laser Timing experiment foreseen using the Atomic Clock Ensemble in Space (ACES) on the International Space Station and already tested for BeiDou satellites.

SLR TRACKING OF THE GNSS CONSTELLATIONS

In the near future, more than 100 GNSS satellites carrying retroreflectors will be operational. This includes GPS Block III satellites, which will carry retroreflectors starting with SV-9. Tracking the full GNSS constellation will pose a big challenge for the ILRS concerning economic use of its ground equipment. Optimized tracking scenarios and session planning strategies will be indispensable.

Already today, the ILRS regularly tracks a large number of GNSS satellites. TABLE 1 shows the number of SLR normal points from ranging to the various GNSS constellations available at the ILRS data centers since 2010. Normal points are compressed full-rate data obtained by averaging individual range measurements typically over five-minute intervals. As part of the Laser Ranging to GNSS Spacecraft Experiment or LARGE project of the ILRS, the tracking of GLONASS satellites was extended to the entire satellite constellation as shown in FIGURE 7.

To assess the capability of SLR for GNSS precise orbit determination based on the number of tracking stations and the distribution of observations, we performed a simple simulation. The covariance analysis included observations of a single SLR station compared to networks of 6 and 17 globally distributed stations. For each station, three normal points were simulated per satellite pass for a full 24-satellite Galileo constellation: two observed at 30° rising and setting elevation angles and one at maximum elevation angle. No unfavorable weather conditions were considered and observations of different stations were assumed to be uncoordinated.

Formal errors of the determined orbits are shown in FIGURE 8 for the radial, along-track, and cross-track components. As expected, orbits determined with observations from one day’s observations by a single station reach formal errors in the few 10s of kilometers range (plot on the left in the first row). If observations from three days are used for orbit determination, the errors on the middle day reduce to about 100 meters (right, first row). The situation significantly improves if a global network of six stations is considered. Even for a single day of observations, an orbit precision of a few decimeters is reached (left, second row) while the orbit uncertainty further decreases to a few centimeters if observations from three days are used (right, second row). If, however, in an effort to reduce the number of observations per pass, only measurements at satellite culmination are acquired, the orbit precision is in the kilometer range for a six-station network and observations from one day (left, third row). If observations from three days are used, the orbit precision is at the meter level (right, third row). Using three normal points per pass for a 17-station network, the orbit precision reaches a few centimeters even within one day (left, last row) and about 1 centimeter for observations from three days (right, last row). It should be noted that the covariance analysis does not consider any systematic observation or orbit modeling error.

This simulation is very simple and not very realistic, but nevertheless indicates the capability of precise orbit determination for GNSS satellites using a limited number of observations per station. The simulations demonstrate two facts. Firstly, even with just two or three normal points per satellite of a GNSS constellation, a significant fraction of the observation time of a station is required. Typically, a mid-latitude station can acquire about 60 normal points per day for a 24-satellite constellation, amounting to several hours of observation time per day. Secondly, the improvement in formal orbit accuracy only increases with the square root of the number of stations. More important than the number of normal points is their distribution along the orbit requiring SLR observations from several stations distributed over the globe.

These two findings make it obvious that coordination among SLR stations is indispensable for making economic use of the observing time of SLR stations while providing good coverage of normal points along all satellite orbits. To cope with weather conditions, this coordinated scheduling of GNSS SLR tracking may have to be optimized in real time.

CONCLUSIONS

SLR has played an important role in validating GNSS-derived satellite orbits for the past several decades. For new GNSS constellations and new orbit types, SLR proves to be essential for calibrating radiation pressure models and allows us to separate orbit- and temperature-induced variations of onboard clocks. Eventually, the role of SLR will become even more important by contributing to the precise orbit determination of GNSS satellites. Given the large number of GNSS satellites from several constellations equipped with retroreflectors, coordination of observation scheduling among SLR stations will be crucial for optimizing the benefit-to-cost ratio.

Concerning the distribution of SLR observations over the constellations, the following conclusions may be drawn:

• For the validation and calibration of radiation pressure models, it is sufficient to acquire well-distributed observations along the orbit of one satellite for each constellation block type for a range of solar beta angles, that is, of one satellite block type per orbital plane.
• For contributing to precise orbit products, optimally combined with microwave GNSS observations, the tracking of all satellites of a constellation is needed. This requires a coordinated scheduling of observations among SLR stations.
• For determination of the gravitational redshift parameter using the two Galileo satellites in eccentric orbits, good coverage of the orbits of both satellites is required (as long as the satellites run on one of the onboard hydrogen maser clocks).
• For BeiDou and NavIC geostationary satellites, SLR coverage is needed for all satellites to resolve biases in the microwave tracking technique.

In the long term, SLR observations could contribute, together with microwave observations, in providing operational high-precision orbit products for all GNSS constellations jointly by the ILRS and the IGS in the framework of the IAG’s Global Geodetic Observing System.
